Full Body Paint Protection Film
Manufacturing-Based Product Definition
This Paint Protection Film (PPF) is developed and manufactured under a factory-controlled process using high-grade TPU material and multi-layer coating technology.
The product is designed to deliver stable mechanical performance, consistent optical clarity, and long-term durability for professional automotive protection applications.
Mechanical Performance & Puncture Resistance
In laboratory-controlled testing, the film achieved a maximum puncture resistance value of 187.1, indicating strong resistance to sharp impact and concentrated force.
This performance reflects the film’s ability to absorb and disperse energy rather than fail under stress, providing reliable protection against stone chips, road debris, and high-contact conditions.
Heat-Activated Self-Healing Structure
The PPF features a heat-activated self-healing top layer, allowing minor surface scratches and swirl marks to recover when exposed to warm water, sunlight, or controlled heat.
This recovery is achieved through elastic memory within the TPU layer, enabling repeated healing cycles without compromising film integrity or clarity.
Optical Stability & Surface Behavior
The film is engineered for high transparency, low orange peel, and long-term color stability.
Its hydrophobic surface reduces contamination adhesion, improves cleanability, and helps maintain surface gloss over extended use.
Anti-yellowing formulation and UV resistance support consistent appearance throughout the service life.
Factory-Controlled Production System
All production stages are completed in-house, including TPU formulation, coating, curing, thickness control, inspection, and packaging.
This closed-loop manufacturing system ensures batch consistency, controlled tolerances, and reliable adhesive performance — key requirements for installers, distributors, and OEM partners.
U.S. Warehouse & Supply Capability
To support global partners with faster fulfillment, we maintain local inventory in the United States.
This enables reduced lead times, stable availability, and responsive supply for North American markets.
Combined with scalable production capacity and OEM/ODM support, the product is positioned for long-term, high-volume distribution.
Paint Protection Film – Key Specifications (Model: V17)
| Category | Specification |
|---|---|
| Product Name | Paint Protection Film (PPF) |
| Brand Name | Highcool |
| Model Number | V17 |
| Style / Grade | Business / Professional Grade |
| Place of Origin | Shanghai, China |
Material & Adhesive System
| Item | Details |
|---|---|
| Base Material | Premium TPU |
| TPU Material Sources | Covestro (Germany) / BASF (Germany & USA) / Lubrizol (USA) |
| Adhesive (Glue) | Ashland Pressure-Sensitive Adhesive |
| Adhesive Features | Stable bonding, clean removal, long-term durability |
Thickness Options
| Available Thickness | Application Level |
|---|---|
| 6.5 mil | Standard protection |
| 7.5 mil | Enhanced durability |
| 8.5 mil | Heavy-duty protection |
| 10 mil | Maximum impact resistance |
Mechanical Performance
| Property | Performance Range |
|---|---|
| Elongation at Break | ≥250% / 350% / 380% / 400% |
| Tensile Strength | ≥20 / 25 / 30 / 35 / 40 / 48 MPa |
| Puncture Resistance | High-performance level (up to 187.1)* |
* Tested under controlled laboratory conditions.
Functional Properties
| Function | Description |
|---|---|
| Self-Healing | Heat-activated surface recovery |
| Anti-Scratch | Resistant to daily abrasion |
| Sand / Stone Proof | Effective impact absorption |
| UV Rejection | ≥99% |
| Infrared (IR) Rejection | ≥90% |
| Privacy Protection | Reduces visibility through glass |
| Anti-Yellowing | Long-term optical stability |
Durability & Aging Performance
| Test Item | Result |
|---|---|
| Aging Resistance Test | 600 hours @ 80°C |
| Outdoor Stability | Designed for long-term exposure |
| Surface Maintenance | Hydrophobic, easy to clean |
Warranty & Certification
| Item | Details |
|---|---|
| Warranty | 5–10 Years (depending on thickness & application) |
| Certifications | ISO 9001 / RoHS / CE |
Supply & Support
| Item | Details |
|---|---|
| Sample Policy | Free A4 size sample available |
| OEM / ODM Service | Supported |
| Supply Capability | Stable mass production |
| U.S. Warehouse | Available for faster local delivery |
Provide Samples
5-10 Year Warranty
OEM/ODM
ISO,ROSH CE,REACH
Is headlight protection film worth it?
Absolutely. It shields headlights from scratches, chips, and UV exposure — extending their lifespan and keeping them clear. Highcool films combine durability with optical clarity for lasting performance and safety.
Does headlight film prevent yellowing?
Yes. Highcool’s UV-blocking technology helps prevent yellowing caused by sun damage and oxidation, so headlights stay bright and clear over time.
How do I protect my aftermarket headlights?
Apply Highcool headlight protection film. It forms a tough, nearly invisible layer that defends against road damage and discoloration — ideal for preserving custom or premium lights.
How long does headlight PPF last?
With proper care, Highcool PPF can last up to 10 years, offering long-term protection against harsh weather, UV rays, and daily impact.
